 Specification |
| . BIOS | 2MB Award PnP BIOS with enhanced ACPI feature for PC99 compliance.
Support 120MB ATAPI floppy disk
Support ZIP disk drive
Support multi-boot from IDE, SCSI, CD-ROM and FDD
Support software clock frequency control
Support Trend Chip Away AntiVirus
Support HDD SMART |
| . On board I/O | 1×Floppy Port (Up to 2.88MB, 3 mode floppy support & LS-120)
1×Serial Ports.
1×Parallel Port (SPP/EPP/ECP)
6×USB (USB 1.0/1.1)
1×PS2 mouse and keyboard
1×IrDA (Pin header on board) |
| . On Board IDE | Dual Ultra DMA33/66/100 IDE ports support 4 enhanced IDE devices |
| . Expansion Slot | 1×64-bit AGP slot. (Support 1×/2×AGP mode)
2×32-bit PCI slot. (PCI specification ver2.1 compliant) |
| . I/O Chip | ITE 8705 |
| . Advanced Features | Support keyboard and mouse Power On feature with ATX power
AC97 Rev.2.1 CODEC onboard
Support hardware monitor function
12V fan connectors (CPU1, system)
Support Wake Up On LAN & MODEM
PC99 color connectors
On board LAN accelerator
On chip VGA |
| . Form Factor | ATX size (220mm×305mm) |
Socket 478
SIS
